The IDP series is a basic, economical, and easy-to-operate analogue (knob-based) model designed for efficient performance. The HA IDP series operates similarly to the standard IDP but features PVDF wetted parts, making it highly compatible with aggressive chemicals due to PVDF’s superior chemical resistance.
The IDP+ series is an advanced version of the IDP, offering high accuracy, a digital display, a level sensor, and an AUX output relay for enhanced automation. Similarly, the HA IDP+ series retains all the features of the IDP+ while incorporating PVDF wetted parts, ensuring exceptional durability and compatibility with highly aggressive chemicals.
| MODEL Series | IDP | IDP+ | HAIDP | HAIDP+ |
|---|---|---|---|---|
| Operating Type | Analog (Knob) Operated | High Accurate Digital Display, Low Level Sensor Dry Run Protection Aux Output For Further Automation. | Analog (Knob) Operated | High Accurate Digital Display, Low Level Sensor Dry Run Protection Aux Output For Further Automation. |
| MECHANICAL | Dosing Capacity Max. Operating Pressure Max. Stoke Per Min. |
0.2-21 LPH 7 BAR 400 |
Dosing Capacity Max. Operating Pressure Max. Stoke Per Min. |
0.2-21 LPH 7 BAR 400 |
| ELECTRICAL | Voltage Length Of Main Cable Max. Power Consumption Electric Safety Class Pollution Degree Ingress Protection |
V 230 (+/-35%) 50 HZ M 2 W 30 - 2 - 3 IP 65 |
Voltage Length Of Main Cable Max. Power Consumption Electric Safety Class Pollution Degree Ingress Protection |
V 230 (+/-35%) 50 HZ M 2 W 30 - 2 - 3 IP 65 |
| SOUND | Max. Sound Pressure Level | dB < 60 | Max. Sound Pressure Level | dB < 60 |
| MOC METAL PARTS | Plunger Copper Insulation Class |
SS 304 Class-H |
Plunger Copper Insulation Class |
SS 304 Class-H |
| MOC WETTED PARTS | Head, injection & foot valve : PP GF/N GF Tube : 6/4mm LDPE Seal : NBR Diaphragm : PTFE |
Head, injection & foot valve : PP GF/N GF Tube : 6/4mm LDPE Seal : NBR Diaphragm : PTFE |
Head, injection & foot valve : PVDF Tube : 6/4mm PVDF Seal : VITON Diaphragm : PTFE |
Head, injection & foot valve : PVDF Tube : 6/4mm PVDF Seal : VITON Diaphragm : PTFE |
| SOLUTION COMPATIBILITY | To Dose Low And Average Concentrated Ph Solution. | To Dose Low And Average Concentrated Ph Solution. | To Dose Highly Acidic Or Basic Concentrated Ph Solution. | To Dose Highly Acidic Or Basic Concentrated Ph Solution. |
